| Brand Name : | NTSJ |
| Model Number : | FPGR-1 |
| Certification : | CE,ISO9001 |
| Price : | Negotiable |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 500 sets/momth |
| Delivery Time : | within 5days after payemnt received |
Double layer glass reactor is a multi-functional reactor, which can be stirred by reaction solvent in the inner layer. The interlayer can be heated / cooled by cold and heat sources (frozen liquid, water or silicone oil). PTFE sealing material, sealing, corrosion resistance, wear resistance, electronic stepless speed regulation, smooth operation, the main structure of stainless steel, aluminum alloy.
| Product Model | PGR-3 | PGR-5 | PGR-10 | PGR-30 | PGR-50 | PGR-100 | PGR-200 |
| Volume(L) | 3 | 5 | 10 | 30 | 50 | 100 | 200 |
| Neck No.on Cover | 4 | 5 | 6 | 6 | 6 | 6 | 6 |
| External Diameter of Inner Vessel(mm) | 150 | 180 | 230 | 330 | 365 | 460 | 600 |
| External Diameter of Outer Vessel(mm) | 200 | 230 | 290 | 365 | 410 | 500 | 650 |
| Cover Diameter(mm) | 150 | 180 | 265 | 265 | 265 | 340 | 340 |
| Vessel Height(mm) | 300 | 400 | 450 | 730 | 850 | 950 | 1200 |
| Motor Power(W) | 40 | 60 | 140 | 140 | 140 | 250 | 750 |
| Vacuum Degree(Mpa) | 0.098 | 0.098 | 0.098 | 0.098 | 0.098 | 0.098 | 0.098 |
| Rotation Speed(rpm) | 50-1400 | 50-600 | 50-600 | 50-600 | 50-600 | 50-600 | 50-600 |
| Torque(Nm) | 0.27 | 0.95 | 2.23 | 2.23 | 2.23 | 3.98 | 6.37 |
| Power(V) | 220 | 220 | 220 | 220 | 220 | 220 | 220 |
| Dimension(mm) | 320*350*900 | 450*450*1200 | 650*650*1900 | 700*500*2100 | 800*600*2300 | 1000*700*2700 | 1200*900*3200 |
Our unjacketed glass reactors come with an oil/water bath included, so that no additional heating circulator is needed.
Durable AC induction motor is designed for continuous operation.
The bottom drain valve has a zero dead space design, to make sure materials inside the vessel is always mixed thoroughly.
All the glassware is carefully crafted by borosilicate 3.3 glass for excellent chemical and physical performance.
The glass lid comes with 5 ports for maximized flexibility in operation (ports for stirring, thermowell, funnel, condenser & vacuum valve).
it is flexiable and can be customized! our wooden boxes are based
on our customer requirements, product weights and size.
Our wooden box will not be heavy, but can protect all parts, the shipping cost will be better for you.
|
|
